Dongfeng 8 Tons Telescopic Crane Truck Equipped with MOOG Hydraulic Cylinder and Mobile Crane Lifting Capacity

Name: Dongfeng 8 Tons Telescopic Crane Truck Equipped with MOOG Hydraulic Cylinder and Mobile Crane Lifting Capacity
Brand: LIYUE
Price: 14 USD

Quality Dongfeng 8 Tons Telescopic Crane Truck Equipped with MOOG Hydraulic Cylinder and Mobile Crane Lifting Capacity wholesale

Brand Name : LIYUE

Model Number : SQ6.3A4 SQ6.3A5

Certification : CE

Place of Origin : Henan, China

MOQ : 1

Price : $14,500.00/units 1-2 units

Packaging Details : Special-purpose packaging for export.

Feature : TRUCK CRANE

Showroom Location : Indonesia

Condition : New

Application : Construction

Rated Loading Capacity : 8 TON

Rated Lifting Moment : 4.85-13 T.M

Max. Lifting Height : 15.2 m

Span : 2280-5580 mm

Warranty : 1 Year

Hydraulic Cylinder Brand : MOOG

Hydraulic Pump Brand : Changjiang

Hydraulic Valve Brand : Liyuan

Engine Brand : YUNNEI

UNIQUE SELLING POINT : High operating efficiency

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Marketing Type : Ordinary Product

Warranty of core components : 1 Year

Core Components : Bearing, Pump

Weight (KG) : 3315 kg

Product name : Truck Mounted Crane

Crane type : Truck Crane Mobile Crane Hydraulic Crane

Hydraulic parts : Famous Brand Hydraulic Parts

Capacity : 8 Ton Truck Crane

Boom type : Hydraulic Straight Arm

Color : Customer Requirements

Usage : Construction Lifting

Rotation Angle : 360 Degree

Installation space : 1200 mm

High quality : Mobile Crane Lifting Capacity

Contact Now

Chinese Factory Cranes supplier 8 tons mini lifting truck mounted crane

Product Description

NOTE: The price is only for crane part.

Dongfeng 8 Tons Telescopic Crane Truck Equipped with MOOG Hydraulic Cylinder and Mobile Crane Lifting Capacity

Project		Unit	Value
Crane Dimension	Crane Model	-	SQ 8T
	Max. Lifting Capacity	kg	8000
	Max. Lifting Height	m	15.2
	Working Radius/ Span	m	2.5-12.5
	Rotation Angle	º	360
	Boom Raising Angle Scope	º	0-75
	Boom Sections	Piece	4
	Outrigger Quantity	Piece	2
	Outrigger Span (Fully Extended)	mm	2280-5580
	Crane Weight	kg	3315
	Hydraulic Tank Capacity	L	160
	Max. Flow Rate of Hydraulic Oil System	L/min	55
	Hydraulic System Rated Pressure	Mpa	27
	Installation Space	mm	1200
Working Parameter	The Basic Boom Length	m	4.85-13
	Max. Lifting Torque	T.m	20
	Max. Slewing Speed	r/ min	2

Truck mounted crane, also known as lorry crane, boom crane, arrow crane, telescopic crane, etc. It can be equipped with cargo boxes of different lengths, generally 3.4m, 4.4m, 5.6m, 8.6m, etc.

Follow up lifting weight can be divided into 3.2 tons, 4 tons, 5 tons, 6.3 tons, 8 tons, 10 tons, 12 tons, 14 tons and 1 ton.

The models of truck mounted cranes mainly include SQ3.2, SQ4, SQ5, SQ6.3, SQ8, SQ10, SQ12, SQ14 and SQ16. Cranes of different tonnage.

Product Process

Famous Brand Hydraulic Parts for our Truck Crane

Prodution Progress

Our truck crane adopts hydraulic parts of famous domestic brands, and each process is strictly controlled. The truck mounted crane not only has good performance, but also has the characteristics of durable, convenient and flexible operation.

Packing & Shipping

All the truck crane will be polish with wax before shipping and will be according the truck type and destination port to choose suitable shipping way.

There are five ways can be chosen, 20GP/ 40HQ container, RORO, bulk cargo vessel, flat rack container.

Client Visit

Henan Liyue Machinery equipment Co., Ltd., located in Lankao County, Henan Province, is a trading and manufacturing combo.

Established in 1980, our company has launched 3T-25T truck cranes, truck mounted cranes and marine crane, and exported to more than 20 countries and regions such as South Africa, Angola, Thailand, Turkmenistan, Kazakhstan, Vietnam, Bhutan and so on. As the manufacturer, we accept OEM/ ODM orders..

Certifications

Our truck crane has a variety of certification, such as CE, ISO, form E, form A, CO and so on. We can also apply for GSP certificate of origin suitable for your national policy according to your requirements.

Optional Device

LIYUE truck mounted crane have our own factory. All the crane are design, made and sold by ourselves. We could supply our products with high quality and good services.
